| Place of Origin: | China |
|---|---|
| Brand Name: | Douwin |
| Certification: | ISO, CE，Energy Saving Technology Certification |
| Model Number: | DW-Combined |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Standard Wooden Case/Packed with Film Firstly, and then Reinforced with Wooden Case for Outer Packing |
| Delivery Time: | 30 days after order |
| Payment Terms: | T/T |
| Supply Ability: | 100 Sets per Month |
| Item Name: | Energy-Saving Technology Vibration Temperature Humidity Chamber With Remote Monitoring Software | Temperature Deviation: | ≤2℃(No Load) |
|---|---|---|---|
| Temperature Uniformity: | ≤2℃(No Load) | Power Supply: | 380VAC±10%,50Hz±1% |
| High Light: | 380V Combined Test Chamber,DW Combined Test Chamber,50Hz Combined Temperature Humidity Chamber |
||
Energy-Saving Technology Vibration Temperature Humidity Chamber With Remote Monitoring Software
Application:
The chamber is suitable for high temperature test,low temperature test,high-low temperature cycle test, constant high temperature-humidity test, and alternating high temperature-humidity test of products (whole machine), parts and materials. At the same time, after matching with the vibration table, it can realize the comprehensive test of temperature-humidity-vibration.
Corresponding Standard:
GB/T 2424.7-2008
GJB 150.3A-2009
GJB 150.4A-2009
GJB 150.9A-2009
Technical Parameters :
| Item Name | Energy-Saving Technology Vibration Temperature Humidity Chamber With Remote Monitoring Software | |
| Model | DW-500 | DW-1000 |
| Workspace Dimensions(MM) | 800×800×800 | 1000×1000×1000 |
| Volume(L) | 500 | 1000 |
| Vibration Table Size | ≤400mm*400mm | ≤600mm*600mm |
| Temperature Change Rate |
5/10/15℃/min(Customizable) |
|
| Temperature Range | -70℃～+150℃ | |
| Humidity Range | 20%～98%RH | |
| Power Supply | 380VAC±10%,50Hz±1% | |
| Temperature Uniformity | ≤2℃(No Load) | |
| Temperature Fluctuation | ≤±0.5℃(No Load) | |
| Temperature Deviation | ≤2℃(No Load) | |
|
Humidity Deviation |
±3%RH(＞75%RH no load),±5%RH(≤75%RH no load) | |
| Resolution | 0.1℃,1%RH | |
|
Standard Configuration |
Φ100mm cable port×2,with soft high-low temperature resistant rubber plug Equipped with standard RS232/RS485/RJ45 communication interface Interior light |
|
Main Features:
| 1. The chamber adopts humanized man-machine interaction interface,it is so easy for buyer to operate it. |
| 2. The chamber is matched remote monitoring software, and provides RS232/RS485/RJ45 standard communication interfaces to realize the remote control and management of the test chamber. |
| 3. The chamber has reasonable layout,stable performance and low noise, so it is very suitable for various laboratories and production lines. |
| 4. The chamber adopts innovative energy-saving technology and has passed the national energy-saving certification. Compared with other similar products,our chamber helps saving 38% energy. |
| 5. The chamber with advanced control logic and PID adjustment technology so that it can maintain long-term stable operation. |
| 6. The chamber has multiple protection functions,which ensure the safety and reliability of product testing. |
| 7. The main components of the chamber are from international premium brands,so the whole machine has high reliability. |
Detail Pictures:
Controlling system: IPC + PLC +Touch screen
The handle lock keeps chamber safe during working
We have different sizes of cable holes
D5/D10/D15mm are optional
Before packing, our tester will check and debug the machine
